APPENDIX 2-5. Parameter Object (Class ID: 0x0F)

Parameter object provides parameter information of NCW-3DHIP.
Following tables indicate specifications of the Parameter object.
This is objects for parameters which are used with NCW-3DHIP.
Class Attribute (Class ID: 0x0F)
ID Name
0x01 Revision
0x02 Max Instance
0x03 Number of Instances
0x08 Parameter Class Discriptor
0x09 Configuration Assembly
Instance
Class Service (Class ID: 0x0F, Instance ID: 0x00)
ID Name
0x01 Get_Attribute_All
0x0E Get_Attribute_Single
Access
Data Type
Get Set
○ UINT
－
○ UINT
－
○ UINT
－
○ WORD
－
○ UINT
－
Read out all attribute values from NCW-3DHIP.
Attribute information returned in response to a request is as follows.
ID
0x01 1 (Revision)
0x02 1 (Max Instance)
0x08 0 (Not available for NCW-3DHIP)
0x09 0 (Not available for NCW-3DHIP)
0x0A 0
Read out one attribute value from NCW-3DHIP.
108
Description
1
0x08(8)
8
Indicates the following parameter characteristics (value:
0x000B).
Bit
0 Supports Parameter Instances
1: Individual Parameter instances are
supported.
1 Supports Full Attributes
1: All Full Parameter Attributes are supported.
2 Must do non-volatile storage Save command
0: Do not have to execute non–volatile storage
save command.
(It automatically executes inside of
NCW-3DHIP.)
3 Param are stored in Non-Volatile Storage
1: Parameters are stored in non–volatile
storage.
0x67
