NSD Absocoder NCW-3DHIPV1R Specifications & Instruction Manual page 129

ID Name
0x02 Configuration Capability
0x03 Configuration Control
Access
Data Type
Get Set
○ DWORD
－
○ ○ DWORD
120
Description
Fixed at 0x00000075
The following table indicates the function which is
supported by NCW-3DHIP.
Bit
0
BOOTP Client
1: Indicates that NCW-3DHIP is capable of obtaining
its network configuration via BOOTP.
1
DNS Client
0: Indicates NCW-3DHIP can not obtain host names
from DNS server.
2
DHCP Client
1: Indicates NCW-3DHIP is capable of obtaining its
network configuration via DHCP.
3
DHCP-DNS Update
0: Indicates NCW-3DHIP cannot return own host
name by the DHCP request.
4
Configuration Settable
1: Indicates the Interface Configuration attribute is
settable.
5
Hardware Configurable
1: Indicates the IP Address number of the Interface
Configuration attribute can be obtained from
hardware settings.
6
Interface Configuration Change Requires Reset
1: Indicates that NCW-3DHIP requires a restart in
order for a change to the Interface Configuration
attribute to take effect.
Configures a NCW-3DHIP network setting option control.
This attribute is stored in the non-volatile memory.
Bit
0-3
Startup Configuration
0: The device use the previously saved interface
setting value.
(Such as the value in the non-volatile memory or the
value of the hardware switch)
1: The device obtain its interface configuration
values via BOOTP.
2: The device obtain its interface configuration
values via DHCP. (Default)
3-15: Reserved
4
DNS Enable
NCW-3DHIP doesn't support.
(2/4)
