NSD Absocoder NCW-3DHIPV1R Specifications & Instruction Manual page 110

Instance Service (Class ID: 0x01, Instance ID: 0x01)
ID
Name
0x01 Get_Attribute_All
0x05 Reset
0x0E Get_Attribute_Single
*1：Instance Attribute 0x05: Bit definition of Status
Bit Name
0
Owned
1
－
2
Configured
3
－
4-7
Extended Device Status
8
Minor Recoverable Fault
9
Minor Unrecoverable Fault
10
Major Recoverable Fault
11
Major Unrecoverable Fault
Read out all attribute values from NCW-3DHIP.
Reset service
The Reset service parameters are the following;
0: Restart
1: All NCW-3DHIP parameters' setting is redesignated to initial values
(factory setting), and restart.
2: All NCW-3DHIP parameters' setting is redesignated to initial values
(factory setting) except communication LINK parameter, and restart.
Read out one attribute value from NCW-3DHIP.
FALSE: Indicates NCW-3DHIP has no owner.
TRUE: Indicates NCW-3DHIP has an owner.
Reserved (fixed at 0)
FALSE: Indicates that NCW-3DHIP is set initial (factory setting) values.
TRUE: Indicates that NCW-3DHIP is changed from initial (factory setting) values.
(The communication setting isn't included.)
Reserved (fixed at 0)
Indicates current NCW-3DHIP status.
This attribute value is changed depending on the device state.
Bit value
0000b Self-Testing or Unknown
0010b At least one faulted I/O connection
0011b No I/O connections established
0100b Non-Volatile Configuration bad
0101b Major Fault – either bit 10 or bit 11 is true
0110b At least one I/O connection in run mode
0111b At least one I/O connection established, all in idle mode
1000b Reserved
1001b Reserved
FALSE: -
TRUE: Indicates that a minor fault (recoverable fault) is detected.
FALSE: -
TRUE: Indicates that a minor fault (unrecoverable fault) is detected.
FALSE: -
TRUE: Indicates that a major fault (recoverable fault) is detected.
FALSE: -
TRUE: Indicates that a major fault (unrecoverable fault) is detected.
101
Description
Definition
Description
