Instance Attribute (Class ID: 0xF6, Instance ID: 0x01, 0x02)
ID Name
0x01 Interface Speed
0x02 Interface Flag
0x03 Physical Address
Access
Data Type
Get Set
○ UDINT
－
○ DWORD
－
○ USINT[6]
－
124
Description
NCW-3DHIP's current state
Speed value (Mbps): 0, 10, 100, 1000, and etc...
NCW-3DHIP's current state
Bit Description
0 Link Status
Indicates the status of link
0: Inactive link
1: Active link
1 Half/Full Duplex
Indicates the duplex mode
0: Half duplex
1: Full duplex
2-4 Negotiation Status
Indicates the status of negotiation
0: Auto-negotiation in progress.
1: Auto-negotiation and speed detection failed.
A default value of the Speed/Duplex when the
detection is faulty: 10Mbps, half duplex
2: Auto negotiation failed but detected speed.
Default value of the Duplex when detection is
fault: half duplex
3: Successfully negotiated speed and duplex.
4: Auto-negotiation not attempted.
Force Speed / Force Interface Speed value is
used.
Manual Setting Requires Speed
5
Fixed at 0
Duplex, Speed Indicates the setting reflected
status setting.
0: Auto-Negotiation / Duplex / Speed are
automatically activated.
1: Indicates that you must issue a Reset service to
the Identity object to activate the change.
6 Local Hardware Fault
Indicates the fault status of NCW-3DHIP.
0: Fault is not detected.
1: Fault is detected.
This is assumed a hard-fault requiring user
intervention.
MAC address of NCW-3DHIP (E8-8E-60-xx-xx-xx)
*: NCW-3DHIP has two ports, but the Physical address
is one.
(1/3)
