Appendix B — Media Specifications

Tickets With Gaps

148 EasyCoder PX4i Bar Code Label Printer User's Guide (Fingerprint Version)
a
c
d
b
(a) Media Width
Minimum: 25 mm (1.00 in)
Maximum: 120 mm (4.72 in)
(b) Liner Width
Minimum (without LTS): 8 mm (0.32 in)
Minimum (with LTS): 12 mm (0.47 in) For more information,
see "Label Taken Sensor" on page
Maximum: 8 dots/mm (203.2): 6,143 mm (241 in)
11.81 dots/mm (300 dpi): 4,162 mm (163 in), provided there is
a sufficient amount of free SDRAM memory
(c) LSS Detection Position: Variable, see
page 132.
e
b
105.
"Label Stop Sensor" on
