Appendix B — Media Specifications

Tickets With Gaps

76
a: Media Width
Maximum:
Minimum:
b: Copy Length
8 dots/mm (203 dpi)
Maximum:
Minimum:
11.81 dots/mm (300 dpi)
Maximum:
Minimum:
* This is the print length limit set by memory constraints.
c: Detection Position
Variable:
d: Detection Slit Length
The length of the detection slit (excluding corner radius) must be
minimum 2.5 mm (0.10 inches) on either side of the detection
position.
e: Detection Slit Height
Maximum:
Minimum:
Recommended:
Paper Type Setup
• Tickets with Gaps
Note: Do not allow any perforation to break the edge
of the media as this may cause the media to split and
jam the printer.
118.0 mm 4.65 inches
25.0 mm 1.00 inches
Fingerprint IPL
1270 mm (50 in.)* 600 mm (23 in.)
6 mm (0.2 in.) 6 mm (0.2 in.)
558.8 mm (22 in.)* 406.4 mm (16 in.)
6 mm (0.2 in.) 6 mm (0.2 in.)
0 to 57 mm 0 to 2.24 inches
26.0 mm 1.02 inches
1.2 mm 0.05 inches
3.0 mm 0.12 inches
