Board details
The following tables list the major components of the EVK. A detailed bill of materials (BOM) list is available in
the design files on the kit webpage.
Jumper settings
REFDES Component
J5 Power selection
jumper
J16 Port 0 PD
regulator power
J17 Port 0 PD
regulator power
EVK components
REFDES Component
U2 EZ-PD™ PMG1-S3 controller
(CYPM1322-97BZXI)
Q10, Q11, Provider FETs
Q14, Q15 (BSC059N04LS6ATMA1)
Q1, Q2, Q20, Consumer FETs
Q21
(ISC240P06LM)
Q22, Q25 Consumer FET CTRLs
(2N70002LT1G)
U3, U6 Buck-boost converter
(NCP81599MNTXG)
U5 5 V buck converter
(TLS4125D0EPV50XUMA1)
U4 3.3 V LDO
(TLE42744GSV33HTMA1)
EVK LEDs
REFDES LED
LED1 KitProg3 status
LED
LED2 KitProg3 power
LED
LED3, LED5 User LED
LED4 Power LED
User guide
Default position Description
1 - 2 (V3P3) 3-pin header to select the EZ-PD™ PMG1-S3 MCU
power source (see
1 – 2 6-pin header to connect the PD regulator Port 0 output
to the power input of the provider path of Port 0
3 – 4
5 – 6
1 – 2 6-pin header to connect the PD regulator Port 1 output
to the power input of the provider path of Port 1
3 – 4
5 – 6
Description
EZ-PD™ PMG1-S3 dual-port USB Type-C PD high-voltage MCU
MOSFET N-CH 40 V, 17 A, TDSON
MOSFET P-CH 60 V, 59 A, TDSON
MOSFET N-CH 60 V, 115 MA, SOT23-3
5-20 V DC-DC buck-boost regulator for USB PD source operation
5 V buck switching regulator for system power
3.3 V Linear Voltage Regulator
Color Description
Amber Indicates the Programming mode and status. The LED functions
only when the KitProg3 Type-C port is connected to a PC. See
the
KitProg3 user guide
Amber Turns ON when the kit is powered through KitProg3 Type-C port
and indicates that the PSoC™ 5LP MCU device is powered.
Green Firmware-driven LED. The kit must be powered to use this LED.
Green Indicates that the PMG1-S3 MCU is powered. The LED is
powered via VDDIO.
9
Power selection jumper)
for details.
