EVAL_PMG1_S3_DUALDRP Evaluation Kit user guide

Revision history

Revision history
Document Date
revision
** 2023-12-07
*A 2024-03-15
*B 2024-09-23
User guide
Description of changes
Initial release.
-Restructured section 2 and 3.
-Updated Safety precautions
-Added Figure 11.
-Corrected GPIO pin number in I/O pinout table, CAPSENSE™ gpio
header, buttons, and slider table as per rev03 schematics
Updated Table 8, Table
-Corrected J21 to J13 and J20 to J18
-Removed note for kit revision
-Updated Table 2.
-Added notes for power-on via Type-C VBUS
-Merged KP3 overvoltage, voltage measurement, and KP3 section into
Appendices section.
-Added section 3.4.
-Removed Onsemi buck boost circuit images from system design
section.
-Added vref for 12-bit SAR ADC section.
-Updated section 3.1.1.
-Added a note for heat dissipation in source mode.
-Updated images in section
-Updated programming and debugging section images with adapters
and tools.
- Updated EVK images to rev 04 board
- Updated schematics to rev 04 board
- Minor fixes throughout the document
53
table.
9, Table 10, Table 11, Table 14
4 with multimeter and adapters.
002-38187 Rev. *B
2024-09-23
