EVAL_PMG1_S3_DUALDRP Evaluation Kit user guide
Board details
REFDES Connector name
J11 2-pin INPUT DC terminal
J12 Barrel jack
User guide
Description
2-pin header to connect 24 V, 10 A input power to the kit for
source operation.
WARNING: Max input should not exceed 24 + 10% V.
Barrel jack connector (2.50 mm ID, 5.50 mm OD) to connect 24
V, 10-A input power to the kit for source operation.
WARNING: Maximum input should not exceed 24 + 10% V. Do
not power J11 and J12 at the same time.
