EVAL_PMG1_S3_DUALDRP Evaluation Kit user guide
Board details
REFDES LED
LED11, CAPSENSE™
LED12 button LEDs
LED6, LED7, CAPSENSE™
LED8, LED9, slider LEDs
LED10
EVK switches
REFDES Button
SW1 KitProg3 mode
SW2 Reset switch
SW3 User switch
Connectors and terminal blocks
REFDES Connector name
J1 KitProg3 USB
J3 KitProg3 debug header
KitProg3 side
J4 KitProg3 debug header
EZ-PD™ PMG1-S3 side
J6, J13 I/O header 17x1
J7 I/O header 34x1
J8 EZ-PD™ PMG1-S3 SWD/JTAG
header
J9, J15 2-pin OUTPUT load terminal
J10, J14 Type-C connector
User guide
Color Description
Green Indicator LEDs for CAPSENSE™ buttons, BTN0 and BTN1.
Firmware-driven LEDs to indicate the state of CAPSENSE™
buttons.
LED11 – BTN0
LED12 – BTN1
Green Indicator LEDs for CAPSENSE™ slider. Firmware-driven LEDs
indicate the state of each sensor in a 5-sensor CAPSENSE™
slider.
LED6 – SLD0
LED7 – SLD1
LED8 – SLD2
LED9 – SLD3
LED10 – SLD4
Description
The mode button is used to put the KitProg3 into Bootloader
mode. See the
This button is used to reset the EZ-PD™ PMG1-S3 MCU. It
connects the EZ-PD™ PMG1-S3 MCU reset (XRES) pin to the
ground.
This button can be used to provide input to the EZ-PD™ PMG1-
S3 MCU. This button pulls the pin to the ground, by default.
Description
USB Type-C connector to connect the kit with a PC for EVK
programming and debugging
10-pin header for connections between KitProg3 and EZ-PD™
PMG1-S3 MCU
10-pin header for connections between KitProg3 and EZ-PD™
PMG1-S3 MCU
Observing and measuring various signals and connecting
external modules for development if required
Observing and measuring various signals and connecting
external modules for development if required
10-pin SWD/JTAG header to program the EZ-PD™ PMG1-S3 MCU
using MiniProg4 or third-party SWD debuggers/programmers.
2-pin header to connect DC load up-to 28 V, 5 A in sink
operation
Type-C receptacle connector for interfacing with Type-C PD
source or sink device
10
KitProg3 user guide for details.
