EVAL_PMG1_S3_DUALDRP Evaluation Kit user guide
EVAL_PMG1_S3_DUALDRP kit system design
EVK pin EVK pin name
J7
11 P5.4
12 P1.0
13 P1.3
14 P7.4
15 P7.3
16 P7.2
17 P7.1
18 P7.0
19 P0.1/LSTX_P1
20 P0.0/LSRX_P1
21 P1.4
22 P2.5
23 P2.7
24 P5.5
25 P7.5
26 P5.2/SHIELD
27 P0.3/DBG2_P1
28 P6.0/SBU1_P1
29 P6.1/SBU2_P1
User guide
PMG1-S3 Primary function Secondary
MCU pin
G1 CAPSENSE™
BUTTON1 LED
output
H2 CAPSENSE™
SLIDER4 LED
output
K4 CAPSENSE™
SLIDER3 LED
output
B11 CAPSENSE™
SLIDER4 input
B13 CAPSENSE™
SLIDER3 input
A14 CAPSENSE™
SLIDER2 input
G14 CAPSENSE™
SLIDER1 input
G15 CAPSENSE™
SLIDER0 input
R7 -
R8 -
M10 CAPSENSE™
SLIDER2 LED
output
A5 CAPSENSE™
SLIDER1 LED
output
A8 CAPSENSE™
SLIDER0 LED
output
H4 CAPSENSE™
BUTTON0 LED
output
CAPSENSE™
A9
BUTTON1 input
H6 CAPSENSE™
shield ground
K6 -
R5 Type-C Port 1
SBU1 signal
P5 Type-C Port 1
SBU2 signal
function
P5.4 (GPIO)
P1.0 (GPIO)
P1.3 (GPIO)
P7.4 (GPIO)
P7.3 (GPIO)
P7.2 (GPIO)
P7.1 (GPIO)
P7.0 (GPIO)
P0.1 (GPIO)
P0.0 (GPIO)
P1.4 (GPIO)
P2.5 (GPIO)
P2.7 (GPIO)
P5.5 (GPIO)
P7.5 (GPIO)
P5.2 (GPIO)
P0.3 (GPIO)
P6.0 (GPIO)
P6.1 (GPIO)
21
Connection details
Connected to LED_BTN1
through a 0-ohm resistor
Connected to LED_SLD4
through a 0-ohm resistor
Connected to LED_SLD3
through a 0-ohm resistor
Connected to SLIDER4
through a 560-ohm resistor
Connected to SLIDER3
through a 560-ohm resistor
Connected to SLIDER2
through a 560-ohm resistor
Connected to SLIDER1
through a 560-ohm resistor
Connected to SLIDER0
through a 560-ohm resistor
-
-
Connected to LED_SLD2
through a 0-ohm resistor
Connected to LED_SLD1
through a 0-ohm resistor
Connected to LED_SLD0
through a 0-ohm resistor
Connected to LED_BTN0
through 0-ohm resistor
Connected to BUTTON0
through 560-ohm resistor
Connected to CAPSENSE™
shield through a no load 560-
ohm resistor
-
Connected to Port 1 Type-C
SBU1 channel
Connected to Port 1 Type-C
