Dimensions for Default Cooling, FE10
9.2.5
600
(23.62)
Figure 56: Dimensions for Default Cooling, FE10, in mm (in)
1
Roof
82
| Danfoss Drives Oy © 2024.09
75.2
155
(2.96)
(6.10)
333
(13.11)
133.5
(5.26)
200
(7.87)
Specifications
1
225
(8.86)
AJ389643274589en-000101 / 172F6409A
