Design Guide | iC7-Automation Air-cooled Enclosed Drives
Dimensions of the 8-port Star Coupler Board
9.2.17
63.6
(2.50)
8
(0.32)
Figure 68: Dimensions of the 8-port Star Coupler Board in mm (in)
94
| Danfoss Drives Oy © 2024.09
19.8
(0.78)
187.5
(7.38)
(0.16)
Ø4.8
(Ø0.19)
196
(7.72)
4
Specifications
AJ389643274589en-000101 / 172F6409A
