Design Guide | iC7-Automation Air-cooled Enclosed Drives
Multicore cables installed in cable ducts.
l
If cable ducts are not used, keep sufficient spacing between the cables.
¢
Do not stack or bundle the cables without proper spacing for longer than 600 mm (24 in).
¢
In other conditions, refer to the local safety regulations, the input voltage, and the load current of the drive.
It is possible to use M12 cable lugs for the mains cables.
Use symmetrical cabling with system modules connected in parallel. Each module must have the same number of cables with an
equal cross-section.
The cable size tables for the enclosed drives can be found with these links.
9.5.2 Mains Cable Size Recommendations, 380–500 V
l
9.5.3 Motor Cable Size Recommendations, 380–500 V
l
9.5.4 Mains Cable Size Recommendations, UL 480 V
l
9.5.5 Motor Cable Size Recommendations, UL 480 V
l
9.5.6 Brake Cable Size Recommendations
l
9.5.7 Brake Cable Size Recommendations, UL
l
Mains Cable Size Recommendations, 380–500 V
9.5.2
Table 40: Mains Cable Size Recommendations, 380–500 V
Model Frame
code
(2)
iC7-60EA3N FE9
05-206A
iC7-60EA3N
05-245A
iC7-60EA3N
05-302A
iC7-60EA3N
05-385A
(2)
iC7-60EA3N FE10
05-480A
iC7-60EA3N
05-588A
Danfoss Drives Oy © 2024.09
I [A]
2
Cable [mm ]
N
206 Cu 1 x (3x70+35)
Al 1 x (3x120+41
Cu)
245 Cu 1 x (3x95+50)
Al 1 x (3x150+41
Cu)
302 Cu 1 x (3x120+70)
Al 2 x (3x95+29 Cu)
385 Cu 2 x (3x95+50)
Al 2 x (3x120+41
Cu)
480 Cu 2 x (3x120+70)
Al 2 x (2x185+57
Cu)
588 Cu 2 x (3x150+70)
Al 2 x (3x240+41
Cu)
NOTICE
Maximum Maximum
cable size number
of mains
2
[mm ]
(1)
cables
95 Cu/Al 2
95 Cu/Al 2
95 Cu/Al 2
95 Cu/Al 2
150 Cu/120 3
Al
150 Cu/120 3
Al
Hole size of Number of
the mains grounding
terminal holes on PE
[mm] busbar
Ø10.5 2
Ø10.5 2
Ø10.5 2
Ø10.5 2
Ø13.5 4
Ø13.5 4
AJ389643274589en-000101 / 172F6409A |
Specifications
Hole size
of the
grounding
terminal
[mm]
Ø10.5
Ø10.5
Ø10.5
Ø10.5
Ø10.5
Ø10.5
109
