Design Guide | iC7-Automation Air-cooled Enclosed Drives
Dimensions of the Control Board
9.2.13
9.8
(0.38)
Ø4.8
(0.19)
Ø4
(0.16)
Figure 64: Dimensions of the Control Board in mm (in)
90
| Danfoss Drives Oy © 2024.09
19.8
(0.78)
69
(2.72)
4.5
8
(0.18)
(0.31)
189
(7.44)
196
(7.72)
1
(0.04)
Specifications
AJ389643274589en-000101 / 172F6409A
