Design Guide | iC7-Automation Air-cooled Enclosed Drives

Dimensions for the Cooling Air Output Flange Option, FE9

9.2.10
200
(7.87)
W
Figure 61: Dimensions for the Cooling Air Output Flange (+OAOF), FE9, in mm (in)
Table 36: Dimensions in mm (in)
W
408 (16.1)
Danfoss Drives Oy © 2024.09
171
(6.73)
Ø 200
(7.87)
W1
Ø 4.5
(0.17)
2441
(96.10)
W1
204 (8.0)
W2
–
AJ389643274589en-000101 / 172F6409A |
Specifications
W3
–
87
