Danfoss iC7-Automation Design Manual page 64
Air-cooled enclosed drives
Hide thumbs
Also See for iC7-Automation:
- Application manual (382 pages) ,
- Design manual (224 pages) ,
- Operating manual (42 pages)
Advertisement
Design Guide | iC7-Automation Air-cooled Enclosed Drives
1
Control cable grommets
1
2
3
Figure 41: Routing of Control Cables from the Top, AE10/11, IE10/11
1
Control cable grommets
3
Tubes, internal diameter 32 mm (1.3 in)
64
| Danfoss Drives Oy © 2024.09
2
Tubes
2
Two corks, to be removed when routing control cables
from the top
Control and Option Installation
AJ389643274589en-000101 / 172F6409A
