I/O and Relay Option Connections

7.6
Figure 37: I/O and Relay Option Terminal Block and Terminal Numbering
Table 15: I/O and Relay Option Signals
Terminal
X13
X51
X101
X102
X103
Table 16: I/O Terminal Signals (X13)
Terminal Function
11 +24 V
out
12 +24 V
out
56 | Danfoss Drives Oy © 2024.09
X13
11 12
13 14
15 16
17 18
19 20
21 22
23 24
31 32
33 34
35 36
37 38
X51
71
72
X101
1
2
3
X102
4
5
6
X103
7
8
Function
I/O terminal
Thermistor input
Relay 1
Relay 2
Relay 3
Terminal block Description
XD2.1:11 Control voltage output.
24 V DC (-15...+20%)
XD2.1:12
Maximum current 200 mA
Short-circuit protected
8 Ethernet speed indicator
10 Ethernet port (X7)
Connector type
2 x 11 spring force connector 0.2–1.5 mm
1 x 2 spring force connector 0.25–2.5 mm
1 x 3 spring force connector 0.25–2.5 mm
1 x 3 spring force connector 0.25–2.5 mm
1 x 2 spring force connector 0.25–2.5 mm
