Design Guide | iC7-Automation Air-cooled Enclosed Drives
Table 31: Dimensions in mm (in)
Product
iC7-60EA3A05-385...590
A
iC7-60EA3A05-658...880
A
iC7-60EA3A05-1000...11
00
iC7-60EA3A05-1260...17
10
80 | Danfoss Drives Oy © 2024.09
D DD W
671 (26.4) 1385 800 (31.5)
(54.5)
679 (26.7) 1385 1200
(54.5) (47.2)
679 (26.7) 1185 2200
(46.7) (86.6)
671 (26.4) 1185 2400
(46.7) (94.5)
W1 W2 W3
800 (31.5) – –
400 (15.7) 800 (31.5) –
400 (15.7) 600 (23.6) 600 (23.6)
600 (23.6) 600 (23.6) 600 (23.6)
Specifications
W4 W5
– 400 (15.7)
– 400 (15.7)
600 (23.6) 400 (15.7)
600 (23.6) 400 (15.7)
