Dimensions for Back-channel Cooling Option, FE9

9.2.7
200
(7.87)
W
Figure 58: Dimensions for Back-channel Cooling (+OABC), FE9, in mm (in)
Table 33: Dimensions in mm (in)
W W1
408 (16.1) 204 (8.0)
84 | Danfoss Drives Oy © 2024.09
53
(2.08)
2450
(96.45)
W2 W3
– –
(91.41)
(64.96)
W4 W5
117 (4.6) 174 (6.9)
Specifications
W1
Ø 200 Ø 4.5
(7.87) (0.17)
2322
103
(4.05)
Ø165
W4
W5
W6 W7
– –
