Dimensions for the Cooling Air Output Flange Option, AE10, AE11, IE10, IE11

9.2.12
200
(7.87)
W
Figure 63: Dimensions for the Cooling Air Output Flange Option (+OAOF), AE10, AE11, IE10, and IE11, in mm (in)
Table 38: Dimensions in mm (in)
W
408 (16.1)
608 (23.9)
808 (31.8)
Danfoss Drives Oy © 2024.09
Ø 200
(7.87)
W3
W2
W1
Ø 4.5
(0.17)
2441
(96.10)
W1
204 (8.0)
192 (7.6)
186 (7.3)
171
(6.73)
W2
–
225 (8.9)
218 (8.6)
Specifications
W3
–
–
218 (8.6)
