Design Guide | iC7-Automation Air-cooled Enclosed Drives
Dimensions for Default Cooling, FE9
9.2.4
200
(7.87)
400
(15.75)
Figure 55: Dimensions for Default Cooling, FE9, in mm (in)
1
Roof
Danfoss Drives Oy © 2024.09
71.3
(2.81)
207
(8.15)
100.5
(3.96)
126.5
(4.98)
Specifications
1
225
(8.86)
AJ389643274589en-000101 / 172F6409A |
