Current Ratings for 6-pulse Enclosed Drives, FE9 and FE10, 400 V AC

9.7.2
Table 49: Current Ratings for 6-pulse Enclosed Drives, FE9 and FE10, 400 V AC
Model code Frame
iC7-60EA3N05-206A FE9
iC7-60EA3N05-245A FE9
iC7-60EA3N05-302A FE9
iC7-60EA3N05-385A FE9
iC7-60EA3N05-480A FE10
iC7-60EA3N05-588A FE10

Current Ratings for 6-pulse Enclosed Drives, FE9 and FE10, UL, 460 V AC

9.7.3
Table 50: Current Ratings for 6-pulse Enclosed Drives, FE9 and FE10, UL, 460 V AC
Model code Frame
iC7-60EA3N05-206A FE9
iC7-60EA3N05-245A FE9
iC7-60EA3N05-302A FE9
iC7-60EA3N05-385A FE9
iC7-60EA3N05-480A FE10
iC7-60EA3N05-588A FE10

Current Ratings for 6-pulse Enclosed Drives, FE9 and FE10, 500 V AC

9.7.4
Table 51: Current Ratings for 6-pulse Enclosed Drives, FE9 and FE10, 500 V AC
Model code Frame
iC7-60EA3N05-206A FE9
iC7-60EA3N05-245A FE9
iC7-60EA3N05-302A FE9
120 | Danfoss Drives Oy © 2024.09
Nominal ratings
I [A] I [A] I
N-in N peak
[A]
203 211 289
241 251 351
297 309 417
379 394 514
472 490 655
578 601 816
Nominal ratings
I [A] I [A] I
N-in N peak
[A]
185 201 283
227 245 334
285 309 408
343 372 514
430 466 619
490 531 776
Nominal ratings
I [A] I [A] I
N-in N peak
[A]
193 201 283
236 245 334
297 309 408
Low overload High overload
I [A] I [A] I [A]
L-in L H-in
199 206 164
236 245 199
291 302 236
371 385 291
463 480 371
567 588 463
Low overload High overload
I [A] I [A] I [A]
L-in L H-in
196 206 154
240 245 181
302 302 222
364 385 279
456 480 336
520 588 421
Low overload High overload
I [A] I [A] I [A]
L-in L H-in
189 196 160
232 240 189
291 302 232
AJ389643274589en-000101 / 172F6409A
Specifications
Typical motor
power, 400 V AC
I [A] P P
H L H
[kW] [kW]
170 110 90
206 132 110
245 160 132
302 200 160
385 250 200
480 315 250
Typical motor
power, 480 V AC
I [A] P P
H L H
[Hp] [Hp]
166 150 125
196 200 150
240 250 200
302 300 250
364 350 300
456 450 350
Typical motor
power, 500 V AC
I [A] P P
H L H
[kW] [kW]
166 132 110
196 160 132
240 200 160
