Removing the Cables

Removing the Cables
Before the module is unseated, the UTP/ScTP and LDM cables must be removed from
the module. To remove the cables (Figure 6-1 and Figure 6-2), complete these steps:
Step
1
2
Figure 6-1: Removing UTP/ScTP Cables
Figure 6-2: Removing the LDM Port Cable
6-2 Removing the Module
Action
Push in the release tab (1) on the side of the connector.
Pull out the cable(s).
7 x
2
8 x
1 x
9 x
2 x
1
x
1 0
3 x
x
1 1
4 x
x
1 2
5 x
2
1
NPB-1060-98F
NPB-1057-98F
