- Page 1 SmartSwitch 9000 9F120-08, 9F122-12 & 9F125-08 User’s Guide 9031174-02...
- Page 3 Notice Notice Cabletron Systems reserves the right to make changes in specifications and other information contained in this document without prior notice. The reader should in all cases consult Cabletron Systems to determine whether any such changes have been made. The hardware, firmware, or software described in this manual is subject to change without notice.
-
Page 4: Fcc Notice
Notice FCC Notice This device complies with Part 15 of the FCC rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. NOTE: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC rules. - Page 5 DECLARATION OF CONFORMITY Application of Council Directive(s): Manufacturer’s Name: Manufacturer’s Address: European Representative Name: European Representative Address: Conformance to Directive(s)/Product Standards: Equipment Type/Environment: We the undersigned, hereby declare, under our sole responsibility, that the equipment packaged with this notice conforms to the above directives. Manufacturer Mr.
-
Page 6: Safety Information
Notice Safety Information CLASS 1 LASER TRANSCEIVERS The 9F120-08, 9F122-12 and 9F125-08 are Class 1 Laser Products The 9F120-08, 9F122-12 and 9F125-08 use Class 1 Laser transceivers. Read the following safety information before installing or operating these The Class 1 laser transceivers use an optical feedback loop to maintain Class 1 operation limits. -
Page 7: Table Of Contents
Chapter 1 Introduction Features... 1-1 Related Manuals... 1-4 Getting Help ... 1-4 Chapter 2 Installing the MicroLAN Modules The Reset Switch ... 2-3 User-Accessible Components... 2-4 Setting the Module Card DIP Switch ... 2-5 Chapter 3 Operation Flexible Network Bus (FNB)... 3-1 System Management Buses ... - Page 8 Contents...
-
Page 9: Chapter 1 Introduction
Introduction The 9F120-08, 9F122-12 and 9F125-08 MicroLAN™ Modules are Dual Attached Concentrator modules for the SmartSwitch 9000 (see Figure 1-1). The 9F120-08 provides eight multi-mode fiber Master ports, the 9F122-12 provides twelve unshielded twisted pair Master ports, and the 9F125-08 provides eight single mode fiber Master ports. - Page 10 Introduction Connectivity The front panel Master port connections are via standard fiber FDDI MIC connectors or RJ-45 Unshielded Twisted Pair ports. Multiple modules can combine to provide connections for up to 168 FDDI stations. All FDDI stations connected to the Master ports are directly attached to the FNB backplane. These ports are not bridged or routed to the FNB backplane.
- Page 11 FDDI FDDI 9F120-08 9F122-12 Figure 1-1. The Concentrator Modules FDDI 9F125-08 Introduction...
-
Page 12: Related Manuals
Introduction Related Manuals The manuals listed below should be used to supplement the procedures and technical data contained in this manual. SmartSwitch 9000 Installation Guide SmartSwitch 9000 Operations Guide SmartSwitch 9000 9C300-1 Environmental Module User’s Guide SmartSwitch 9000 9C214-1 AC Power Supply User’s Guide SmartSwitch 9000 Module Local Management User’s Guide Getting Help For additional support related to this device or document, contact the Cabletron Systems Global Call... -
Page 13: Installing The Microlan Modules
Installing the MicroLAN Modules SmartSwitch 9000 MicroLAN Modules can be installed in any of the 14 slots that are available. To install, follow the steps below: 1. Remove the blank panel, covering the slot in which the MicroLAN Module will be installed. All other slots must remain covered to ensure proper airflow and cooling. - Page 14 Installing the MicroLAN Modules Metal Back-Panel Figure 2-1. Installing the MicroLAN Module Module Module Guides Warning: Ensure that the circuit card is between the card guides. Lock down the top and bottom plastic tabs at the same time, applying even pressure. Plastic Tab Jack for ESD Wrist Strap...
-
Page 15: The Reset Switch
The Reset Switch The Reset switch is located on the front panel, under the top plastic tab, as shown in Figure 2-2. It serves two functions: • Pressing the Reset switch twice within three seconds causes the processor (i960) to reset. •... -
Page 16: User-Accessible Components
Installing the MicroLAN Modules User-Accessible Components Figure 2-3 shows the various components that are accessible to the user. These consist of an eight-position dip switch (explained in the next section), replaceable PROMs and sockets for RAM. These will be used for future upgrades. Instructions for installing the components will be supplied with the upgrade kit. -
Page 17: Setting The Module Card Dip Switch
Setting the Module Card DIP Switch An eight-switch DIP switch is located on the module card, as shown in Figure 2-3 and Figure 2-4. The functions of the switches are listed in Table 2-1. Figure 2-4. Location of Module DIP Switch Installing the MicroLAN Modules... - Page 18 Installing the MicroLAN Modules See the Cautions at the end of this table. Switch Function Password NVRAM Force BootP Download Reserved Reserved Reserved Reserved Reserved Caution: Do not toggle Switch 8 unless you intend to reset the user-configured passwords to their factory default settings. CAUTION Caution: Do not toggle Switch 7 unless you intend to reset the user parameters to the factory default settings.
-
Page 19: Chapter 3 Operation
Operation The MicroLAN Modules, as shown in Figure 3-1, provide concentrator ports that connect directly to the FNB bus. Each port can connect to either ring (FNB-1 or FNB-2). This is software configurable via local or remote management. DC/DC Converter Fiber port Fiber... -
Page 20: System Management Buses
Operation System Management Buses There are two management channels within the SmartSwitch 9000 system: the SMB-1 and the SMB-10. These buses provide out-of-band management and inter- module management communication. SMB-1 Bus The SMB-1 is a 1 Mbps management bus located within the SmartSwitch 9000. This bus is utilized by all diagnostic controllers in the system including connectivity modules, power supply modules and the environmental module. -
Page 21: System Diagnostic Controller
System Diagnostic Controller This diagnostic controller is composed of a Z-80 microprocessor and its supporting logic. The diagnostic controller is designed to control the power-up sequencing of modules, monitor the concentrator modules input and output power parameters, keep watch over the main host processor, as well as monitor the temperature and control the SMB LANVIEW diagnostic LED. - Page 22 Operation...
-
Page 23: Lanview Leds
The front panel LANVIEW LEDs indicate the status of the module and may be used as an aid in troubleshooting. Shown in Figure 4-1 is the LANVIEW LEDs of the concentrator modules. FDDI 9F120-08 System Status and CPU FNB Receive FNB Transmit FDDI Port Figure 4-1. The LANVIEW LEDs Chapter 4 FDDI 9F122-12... - Page 24 LANVIEW LEDs The functions of the System Management Bus (SMB) and the CPU LEDs are listed in Table 4-1. LED Color Green Yellow Yellow/Green Red (Flashing) The functions of the FNB Receive LEDs are listed in Table 4-2. LED Color Yellow (Flashing) The functions of the FNB Transmit LEDs are listed in Table 4-2.
- Page 25 There is one FDDI Port LED for each Master port. The functions of the FDDI Port LEDs are listed in Table 4-4. Table 4-4. FDDI Status LEDs LED Color Green Yellow Red (Flashing) State Link, Activity, Port enabled Link, No Activity, Port enabled No link, Port disabled Link, Port disabled No link, No activity, Port enabled...
- Page 26 LANVIEW LEDs...
-
Page 27: Chapter 5 Specifications
Specifications Safety It is the responsibility of the person who sells the system to which the module will be a part to ensure that the total system meets allowed limits of conducted and radiated emissions. CAUTION This equipment meets the following safety requirements: •... -
Page 28: Physical
Up to 2 kilometers on multimode fiber-optic cable as specified by ANSI MMF-PMD. 9F125-08 40 kilometers (max), 25 kilometer (typical) on single-mode fiber-optic cable as specified by ANSI SMF-PMD. 9F122-12 100 meters on unshielded twisted pair cable as specified by ANSI TP-PMD.
