[4] Set Default Gateway

This option sets the default gateway, if necessary, for the in-band interface. This is the
address of a router that the module uses when communicating with a remote host. The
default gateway address must be an address in the same subnet as your in-band address.
The following example shows the dialog associated with this option:
VNswitch 900CG
===========================================================
Format: The standard 4 octet dotted decimal notation in which
===========================================================
SET IN-BAND INTERFACE DEFAULT GATEWAY ADDRESS
octet of the address is represented as a decimal
each
value, separated by a '.' character.
example: 16.20.40.156
To delete the address, enter 0 in the appropriate
address field.
Default Gateway [] : 16.126.16.254 <Return>
Default Gateway Address Set.
Press Return for IP Configuration Menu . . .
Configuring the Module in a DEChub ONE 4-11
