- Page 1 SmartSwitch 9000 9T125-24 User’s Guide 9032053-01...
- Page 3 Notice Notice Cabletron Systems reserves the right to make changes in specifications and other information contained in this document without prior notice. The reader should in all cases consult Cabletron Systems to determine whether any such changes have been made. The hardware, firmware, or software described in this manual is subject to change without notice.
-
Page 4: Fcc Notice
Notice FCC Notice This device complies with Part 15 of the FCC rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. NOTE: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC rules. -
Page 5: Declaration Of Conformity
DECLARATION OF CONFORMITY Application of Council Directive(s): Manufacturer’s Name: Manufacturer’s Address: European Representative Name: European Representative Address: Conformance to Directive(s)/Product Standards: Equipment Type/Environment: We the undersigned, hereby declare, under our sole responsibility, that the equipment packaged with this notice conforms to the above directives. Manufacturer Mr. - Page 6 Notice...
-
Page 7: Table Of Contents
Getting Help ... 1-4 Chapter 2 Installation Unpacking the Module... 2-1 User Accessible Components ... 2-2 Setting the Module Card DIP Switch ... 2-3 Ring Speed ... 2-4 Installing the MicroLAN Module ... 2-4 The Reset Switch ... 2-6 Chapter 3 Operation Bridging ... - Page 8 Contents...
-
Page 9: Chapter 1 Introduction
Introduction The 9T125-24 Module MicroLAN™ Switch Module, shown in Figure , is a three-port Token Ring switch module. This module supports two separate front panel Token Rings with twelve HUB connections, and an interface to the FNB backplane. Features Processor The 9T125-24 Module is equipped with an advanced Intel i960 microprocessor. - Page 10 Introduction Figure 1-1. The 9T125-24 Module MicroLAN Module TOKEN RING 9T125-24 16 Mb...
- Page 11 Management Information Base (MIB) Support The 9T125-24 Module provides MIB support including: • IETF MIB II (RFC 1213) • IETF RMON MIB (RFC 1271 and 1513) • IETF Bridge MIBs (RFC 1493 and 1525) • IEEE 802.5 Token Ring MIB (RFC 1231) •...
-
Page 12: Related Manuals
Introduction Related Manuals The manuals listed below should be used to supplement the procedures and technical data contained in this manual. SmartSwitch 9000 Installation Guide SmartSwitch 9000 Operations Guide SmartSwitch 9000 9C300-1 Environmental Module User’s Guide SmartSwitch 9000 9C214-1 AC Power Supply User’s Guide SmartSwitch 9000 Local Management User’s Guide Getting Help For additional support related to this device or document, contact the Cabletron Systems Global Call... -
Page 13: Chapter 2 Installation
Installation To install the 9T125-24 Module into the SmartSwitch 9000 chassis, follow the procedures detailed in this chapter. Unpacking the Module 1. Carefully remove the module from the shipping box. (Save the box and packing materials in the event the module must be reshipped.) 2. -
Page 14: User Accessible Components
User Accessible Components Figure 2-1 shows the various components that are accessible to the user. These consist of an eight position dip switch (explained in the next section), replaceable PROMs and sockets for RAM. These will be used for future upgrades. -
Page 15: Setting The Module Card Dip Switch
Setting the Module Card DIP Switch An eight position DIP switch is located on the module card as shown in Figure 2-1 and in Figure 2-1. The functions of this switch are listed in Table 2-1. See the Cautions at the end of this table. -
Page 16: Ring Speed
The SmartSwitch 9000 MicroLAN Module may be installed into any of the 14 slots that are available. To install, follow the steps below: 1. Switch off the power supplies and remove all power from the SmartSwitch 9000 chassis. 2. Remove the blank panels, covering the slots that the module is being mounted in. - Page 17 Metal Back-Panel Module Guides Warning: Ensure that the circuit card is between the card guides. Lock down the top and bottom plastic tabs at the same time, applying even pressure. Figure 2-2. Installing the MicroLAN Module Plastic Tab Jack for ESD Wrist Strap Module Installation...
-
Page 18: The Reset Switch
Installation The Reset Switch The Reset switch is located on the front panel, under the top plastic tab as shown in Figure 2-3. It serves two functions: • Pressing the reset switch twice within three seconds causes the processor (i960) to reset. -
Page 19: Chapter 3 Operation
Operation The 9T125-24 MicroLAN Module provides connectivity between the front panel Token Ring(s) and the FDDI rings on the backplane (FNB-1 or FNB-2). SmartSwitch 9000 modules connect to either the Internal Network Bus (INB) or the Flexible Network Bus (FNB) bus. The 9T125-24 module connects to the FNB bus. -
Page 20: Transparent Bridging
Operation Transparent Bridging Transparent Bridging is provided between all three interfaces and is accomplished by building a Source Address Table (SAT) from source MAC/physical addresses and using the SAT to make forwarding decisions. The 9T125-24 prevents unnecessary network traffic from passing through the module by implementing two separate filtering processes —... -
Page 21: Spanning Tree Algorithm
In order for source routing to work, the source station must determine the proper route to reach the desired destination. To accomplish this: 1. The source station sends out frames called All Route Explorer (ARE) or Single Route Explorer (SRE) frames onto the network. All Source Route Bridges recognize these frames and forwards them to their outbound ports. -
Page 22: System Management Buses
Operation System Management Buses There are two management channels within the SmartSwitch 9000 system: the SMB-1 and the SMB-10. These buses provide out-of-band management and inter- module management communication. SMB-1 Bus The SMB-1 is a 1Mbs management bus located within the SmartSwitch 9000. This bus is utilized by all diagnostic controllers in the system including connectivity modules, power supply modules and the environmental module. -
Page 23: Dc/Dc Converter
DC/DC Converter The DC/DC converter converts the 48 VDC on the system power bus to the necessary operating voltages for its host network services module. The diagnostic controller controls the operation of the DC/DC converter. FNB Interface SmartSwitch 9000 modules are designed with one of two attachment options. One allows a module to dual attach to either FNB-1 or FNB-2;... - Page 24 Operation...
-
Page 25: Lanview Leds
LANVIEW LEDs The front panel LANVIEW LEDs, shown in Figure 4-1, indicate the status of the module and may be used as an aid in troubleshooting. FNB Receive Token Ring Speed (16Mb) TOKEN RING TOKEN RING 9T122-24 9T125-24 System Status FNB Transmit Token Ring MAC Transmit 16 Mb... - Page 26 LANVIEW LEDs The functions of the two System Status LEDs, System Management Bus (SMB) and the CPU, are listed in Table 4-1. Table 4-1. System Status LEDs (SMB and CPU) LED Color Green Yellow (Flashing) Yellow/Green Red (Flashing) The function of the FNB Receive LED is listed in Table 4-2. LED Color Green Yellow (Flashing)
- Page 27 The function of the Token Ring MAC Receive LEDs is listed in Table 4-4. Table 4-4. Token Ring Receive LEDs LED Color Green Link, No activity, Port enabled Yellow (Flashing) Link, Activity (Flashing rate indicates rate of activity). No link, No activity The function of the Token Ring MAC Transmit LEDs is listed in Table 4-5.
- Page 28 LANVIEW LEDs...
-
Page 29: Chapter 5 Specifications
Specifications Safety It is the responsibility of the person who sells the system to which the module will be a part to ensure that the total system meets allowed limits of conducted and radiated emissions. CAUTION This equipment meets the safety requirements of: •... -
Page 30: Physical
Specifications Physical Dimensions 35.0 D x 44.0 H x 3.0 W centimeters (13.8 D x 17.4 H x 1.2 W inches) Weight Unit: Shipping: Electrical CPU: Shared DRAM Memory: Local DRAM Memory: Flash: Token Ring Interfaces: NVRAM: 1.36 kg. (3 lb.) 1.81 kg.
