Connecting to the Setup Port

To connect to the setup port on the module, complete the following steps:
Step
1
2
The following legend identifies the setup port cabling in Figure 3-1:
Item
1
2
3
Action
Ensure that the transmit and receive baud rates on the setup port device
are set to 9600 baud.
Connect the setup port device to the setup port connector on either the
MultiSwitch 900 or the DEChub ONE docking station.
Description
Out-of-Band Management (OBM) Port
Setup Port
Setup Port Device
Connecting to the Setup Port
Installing the Setup Port Cable 3-3
