Start Redirect Mode - Cabletron Systems DIGITAL VNswitch 900CG Installation And Configuration Manual

[9] Start Redirect Mode

[9] Start Redirect Mode

The Start Redirect Mode option redirects the DIGITAL MultiSwitch 900
Chassis Manager setup port to the setup port of any network module (such as the
VNswitch 900CG) that is installed into the MultiSwitch 900. This option allows you
to configure or obtain status of an installed network module by accessing the specified
network module's installation menu.
After you choose the Start Redirect Mode option from the DIGITAL
MultiSwitch 900 INSTALLATION MENU, the screen prompts you for a slot
number, as shown in the following example. After you enter the number of the slot in
which the VNswitch 900CG is installed, the console is redirected to this slot.
The slot number may change to reflect the slot number in which your module is
installed.
The following example shows you how to redirect the console to a specific slot:
Enter the slot number for redirection (1-8):
Console redirected to 3: VNswitch 900CG
Attempting connection [Ctrl/C to Abort]...
If the redirection is successful, after you press Return, the VNswitch 900CG
INSTALLATION MENU appears on your screen. If redirection is not successful, for
example, you entered a number for an empty slot, you can press Return to start again
at the DIGITAL MultiSwitch 900 INSTALLATION MENU.
5-4 Configuring the Module in a DIGITAL MultiSwitch 900
NOTE
3 <Return>
