Table 2-1: Front Panel LEDs and Connectors
Item Icon Name
Fast Ethernet LEDs and Connectors (Items 1-11)
1 Power LED
2 Module OK
LED
3 VNbus Status
LED
4 VNbus
Activity LED
5 Load/Dump/
Management
(LDM) Port
Status LED
6 LDM Activity
LED
7 LDM Port
connector
8 Reset/Dump
Button
1
The VNbus Status and Traffic LEDs display different indications during a load state. Refer to the
release notes for current descriptions.
Module Components
Description
Lights when the module has power.
Lights when the module passes self-test.
Shows if the module is properly attached
1
to a VNbus backplane.
1
Indicates network traffic.
Indicates the link status of the Load/
Dump/Management port.
Indicates when the LDM port is
transmitting or receiving packets.
Dedicated 10BaseT Ethernet port.
Supports loads and upline dumps of an
operational image. This port is wired as a
straight-through connector.
Used to either reset the module or
perform an upline dump of the
operational image, followed by a reset. If
this button is pressed as operational code
initializes, the module will reset to
current settings.
If the module is in operation mode, hold
the button for five seconds. Use a non-
conductive device to press the button.
(continued on next page)
Installing the DIGITAL VNswitch 900CG 2-3
