Task 6: Connect the Duplex SC Cables

The DIGITAL VNswitch 900CG uses both Single-Mode Fiber (SMF) and Multi-
Mode Fiber (MMF) port connectors.
Some fiber optic equipment can emit laser or infrared light that can injure your
eyes. Never look into an optical fiber or connector port. Always assume the cable
is connected to a light source.
Table 2-3 and Table 2-4 describe supported Short Wave Length and Long Wave
Length cable distances.
Table 2-3: Short Wave Length - Black (HP 5601 - 850)
Fiber Size
62.5 Microns (MMF):
50.0 Microns (MMF)
Table 2-4: Long Wave Length - Blue (HP 5611 - 1300)
Fiber Size
62.5 Microns (MMF)
50.0 Microns (MMF)
10.0 Microns (SMF)
* requires offset launch fiber jumper
MMF indicates Multi-Mode Fiber
SMF indicates Single-Mode Fiber
WARNING
Fiber Bandwidth
160MHz per Kilometer
200MHz per Kilometer
400MHz per Kilometer
Fiber Bandwidth
500MHz per Kilometer
400MHz per Kilometer
Installing the DIGITAL VNswitch 900CG 2-13
How to Install the Module
Distance
2 to 220 Meters
2 to 275 Meters
2 to 250 Meters
Distance
2 to 550 Meters*
2 to 550 Meters*
2 to 5,000 Meters
