How to Install the Module
How to Install the Module
The hot-swap feature allows you to install the module into the DIGITAL MultiSwitch
900 without turning off power. Seating the module initiates power-up.
To install the module, complete the following tasks.
Task 1: Compare the Power Ratings
Compare your module's power requirements (1) with the values shown in the Chassis
Manager (2) status display (Figure 2-3).
If any of the module's power requirements exceed the values shown in the status
display, add another power supply (see the DIGITAL MultiSwitch 900 Owner's
Manual).
Figure 2-3: Sample Power Ratings
1
2-8 Installing the DIGITAL VNswitch 900CG
51.5 W
8.8 A
5 V
0.12 A
12 V
0.52 A
15 V
2
Available: 90.5 W
5V: 13.0 A, 15V: 3.5 A
NPB-1054-98F
