[4] Configure IP

[3] Set Out-of-Band Interface IP Address

This option prompts you to change or enter the IP address and subnet mask for the out-
of-band interface. The module does not need to be configured with a subnet mask for
SNMP communications when management stations are on the same subnet as the
module.
The format for these values is the standard 4-octet dotted decimal notation, where each
octet of the address is represented as a decimal value, separated by a decimal point (.).
If the module is in a MultiSwitch 900, the OBM feature allows you to manage your
module through the OBM port located on the MultiSwitch 900. To enable out-of-band
management, you need to assign an OBM IP address.
The following example shows the dialog associated with this option:
VNswitch 900CG - slot 3
================================================================
Format: The standard 4 octet dotted decimal notation in which
.
To delete the address, enter 0 in the appropriate address
field.
================================================================
Interface
In-band
OBM Port
================================================================
Enter the IP address [16.20.66.156] : 16.20.54.155 <Return>
Enter the Subnet Mask [255.255.255.0] : 255 255 192 0 <Return>
Press Return for IP Configuration Menu...
5-12 Configuring the Module in a DIGITAL MultiSwitch 900
OUT-OF-BAND INTERFACE IP ADDRESS CONFIGURATION
each
octet of the address is represented as a decimal
value, separated by a '.' character.
example: 16.20.40.156
IP Address Subnet Mask
16.20.216.91 255.255.255.0
16.20.66.156 255.255.255.0
Other Info
08-00-2B-A3-CD-08
Speed 9600 bps
