[4] Configure IP
This option provides you with IP configuration selections.
For any of the IP Configuration menu options to take effect, the module needs to
be reset. Use [2] Restart with Current Settings from the
VNswitch 900CG INSTALLATION MENU. Allow approximately 1 minute
for the module to restart and complete self-test.
The following example shows the dialog associated with this option:
VNswitch 900CG
=========================================================
=========================================================
The following pages describe the IP Configuration options:
Topic
[1] Set SNMP Read/Write Community
[2] Set In-Band Interface IP Address
[3] Set Out-of-Band Interface IP Address
[4] Set Default Gateway
IP CONFIGURATION
* * * * * * * * * * * * * * * * * * * * * * * * * * *
Configuration will not take effect until module is
restarted
* * * * * * * * * * * * * * * * * * * * * * * * * * *
[1]
Set SNMP Read/Write Community
[2]
Set In-Band Interface IP Address
[3]
Set Out-of-Band Interface IP Address
[4]
Set Default Gateway
[5]
Return to Main Menu
Enter selection number : n
Configuring the Module in a DIGITAL MultiSwitch 900 5-9
NOTE
<Return>
[4] Configure IP
Page
5-10
5-11
5-12
5-13
