Module Components

Back Panel Components

Table 2-2 describes the back panel components that are illustrated in Figure 2-2.
Table 2-2: Back Panel Components
Item
1
2
3
4
5
6
7
2-6 Installing the DIGITAL VNswitch 900CG
Name
Locking tab
48-pin connector
Grounding bolt
Manufacturing label
160-pin connector
Mounting tab
Grounding fingers
Description
Locks the module into a MultiSwitch 900
backplane or into a DEChub ONE docking
station. Contains the hot-swap switch lever.
Provides network and power connections to
the module when the module is installed in a
MultiSwitch 900 or DEChub ONE docking
station.
Provides a chassis grounding connection
between the module and the MultiSwitch 900
or the DEChub ONE docking station.
Lists the module's part number, serial
number, revision level, and power
requirements.
Provides network and power connections to
the module when the module is installed into
a MultiSwitch 900 or a DEChub ONE
docking station.
Secures the module when it is installed into a
MultiSwitch 900 or a DEChub ONE docking
station.
Provide additional chassis grounding
between the module and a MultiSwitch 900 or
a DEChub ONE docking station.
