[2] Set In-Band Interface IP Address

This option prompts you to change or enter the module's in-band IP address, subnet
mask, and default gateway for the in-band interface. If an IP address was previously
configured, the screen displays an in-band IP address. The factory default setting is no
in-band address.
You do not need to configure the module with a subnet mask for SNMP
communications with management stations located on the same subnet as the module.
The following example shows the dialog associated with this option:
VNswitch 900CG
================================================================
Format: The standard 4 octet dotted decimal notation in which
.
To delete the IP address, enter 0 in the appropriate address
field.
Interface
In-Band
OBM Port
================================================================
Enter the IP address [16.20.126.24] : 16.20.54.156 <Return>
Enter the Subnet Mask [255.0.0.0] : 255.255.0 0 : <Return>
IN-BAND INTERFACE IP ADDRESS CONFIGURATION
each octet of the address is represented as a decimal
value, separated
by a '.' character.
example: 16.20.40.156
IP Address Subnet Mask
16.20.216.91 255.255.255.0
16.20.66.156 255.255.255.0
Press Return for IP Configuration Menu.....
Configuring the Module in a DEChub ONE 4-9
[4] Configure IP
Other Info
08-00-2B-A3-CD-08
Speed 9600 bps
