Connection
IMPORTANT
When installing the gateway at the end of the bus with the termination resistor enabled, do not
install an additional termination resistor at that end.
NOTE
See the Wiring diagram (page

5.2.6. Connection Procedure for Home Automation

Connect the Home Automation Ethernet cable to the gateway's Ethernet Port. The correct cable to use depends
on where the gateway is connected:
• Connecting directly to a Home Automation device: use a crossover Ethernet UTP/FTP CAT5 or higher cable.
• Connecting to a hub or switch of the LAN of the building: use a straight Ethernet UTP/FTP CAT5 or higher
cable.
NOTE
When commissioning the gateway for the first time, DHCP will be enabled for 30 seconds. During
that time, if there is a DHCP server, an IP address will be automatically assigned to the gateway. If
there is no DHCP, you can type an IP address of your choice. After that time, the default IP address
192.168.100.246 will be automatically set.
IMPORTANT
If communicating through the LAN of the building, contact the network administrator and make sure
traffic on the used port is allowed through all LAN paths.
NOTE
See the Wiring diagram (page

5.2.7. Connection to a PC for Configuration

Use the supplied USB Mini-B type to USB Type-A cable to connect the gateway through its Console port to a PC
to configure it with Intesis MAPS.
NOTE
You can use the Ethernet Port to connect the gateway and the PC instead.
NOTICE
Find all you need to know about the gateway configuration and Intesis MAPS in the
User manual for IN770AIR00xO000.
NOTE
See the Wiring diagram (page
USER MANUAL Version 1.0.6
10).
10).
10).
Hitachi VRF with KNX, Serial and IP support
Intesis MAPS
Page 15 of 38
