PneuAlpha2 Simple Application
9 ) Using the "
10 )Press the "OK" and a Directset of the Low limit can be entered using the "+ and -" keys.
11 )Press the "OK" key to accept the value and use the "
limit value. Press the "OK" key and a directset value can be entered using the "+ and -"
keys.
12 )Press the "ESC" key until the FBd is displayed.
and " arrows highlight the high and low limit values.
Function Blocks 6
and " arrows to highlight the high
6 - 31
