Metal Speed Controller Low Profile Type ASBL Series Safety Instructions These safety instructions are intended to prevent hazardous situations and/or equipment damage. These instructions indicate the level of potential hazard with the labels of “Caution,” “Warning” or “Danger.” They are...
Page 4
Metal Speed Controller Low Profile Type ASBL Series Safety Instructions Caution We develop, design, and manufacture our products to be used for automatic control equipment, and provide them for peaceful use in manufacturing business. Use in non-manufacturing business is not covered.
Design/ Selection 2. Specific Product Precautions Warning Design/ Selection (7) Speed controllers are designed to control Warning the speed of the actuator. (1) Confirm the specifications. (8) The surface of brass may turn black The products are designed to be used in depending on the storage and operating compressed air systems (including vacuum) only.
Page 6
Mounting Mounting Warning Warning (7) Verify the air flow direction. Hex Key (Nominal) Connection Mounting backward is dangerous, because the Metric [mm] Imperial [Inch] Thread speed adjustment needle will not work and the M5, 10-32UNF actuator may lurch suddenly. R1/8, G1/8 NPT1/8 7/32"...
Page 7
Mounting Mounting Caution Caution (1) For M5, 10-32UNF (3) The proper tightening torques for hexagon ① Tightening method lock nuts are shown in the table below. First, tighten it by hand, then give it an For standard installation, turn 15 to 30°using a additional 1/6 turn to 1/4 turn with a wrench.
Page 8
Precautions for One-Touch Tube Fittings Piping Piping Caution Caution (2) Preparation before piping Before piping is connected, it should be ② Removal of the tube thoroughly blown out with air (flushing) or 1) Push the release button flange evenly and washed to remove chips, cutting oil and other sufficiently to release the tube.
Page 9
Air Supply Recommended Piping Conditions Caution Caution (1) When connecting piping to the One-touch (1) Install an air filter. fitting, use a pipe length with sufficient Install an air filter upstream near the valve. margin, in accordance with the piping For the filtration rating, select 5 μm or below, or conditions shown in Figure 1.
Page 10
Maintenance Caution (4) Removal of equipment, and supply/exhaust of compressed air Before components are removed, first confirm that measures are in place to prevent workpieces from dropping, run-away equipment, etc. Then, Cut the supply pressure and electric power, and exhaust all compressed air from the system using the residual pressure release function.
3. Application This product is designed to provide a temporary intermediate stop of a pneumatic actuator. 4. Specifications Fluid Proof pressure 1.5MPa Maximum operating pressure 1.0MPa 0.1MPa Minimum operating pressure -5 to 60℃ (No freezing) Ambient and fluid temperature (note 1) Applicable tube materials FEP, PFA, Nylon, Soft nylon, Polyurethane, Polyolefin Note1: Check the maximum operation pressure of the tubing.
6. Construction Seal method:Sealant Seal method:Gasket seal For R,NPT thread For M5,10-32UNF Seal method:Face seal For G thread Meter-In Meter-Out -11-...
