PneuAlpha2 Simple Application

Setup of the Pulse Function Block directly from the

1 ) Allocate the input pin to be used for the function block.

2 ) Press the "OK" key with the cursor in the function block. The function block edit screen is

displayed as shown.

3 ) Select Setup FB using the "

and " keys the initiation type for the pulse operation.

4 ) Press the "OK" key to return to the function block edit screen.

PneuAlpha2 Series Controller

and

" keys and press the "OK" key. Select using the "

Function Blocks 6

6 - 12
