PneuAlpha2 Simple Application

Setup of the Delayed Alternate Function Block directly from the

Controller

1 ) Allocate the input pin to be used for the function block.

2 ) Press the "OK" key with the cursor in the function block. The function block edit screen is

displayed as shown.

3 ) Press the "OK" key to set the Time unit for the delayed alternate output. Choose either a

10ms, 100ms or 1s time interval using the "

the "OK" key when ready.

4 ) Return to the function block edit screen. Using the "

and press the "OK" key.

5 ) Press the "OK" to accept subsequently use the "ESC" key to return to the FBd.

and

" keys to highlight the option and press

and

" keys highlight the Setup FB

Function Blocks 6

PneuAlpha2 Series

6 - 76
