PneuAlpha2 Simple Application

Setup of the Offset Gain Function Block directly from the

1 ) Allocate the input pin to be used for the function block.

2 ) Press the "OK" key with the cursor in the function block. The function block edit screen is

displayed as shown.

3 ) Press the "OK" Key and enter the function block settings using the "

parameters A, B, X, C, Low limit and High limit have to be speciﬁed for the linear

expression to operate correctly..

4 ) Using the "

and -" keys can be entered, subsequently press the "OK" key to accept the Direct Set

value. (Repeat operation for B)

5 ) Highlight X using the "

6 ) The Analog In channel can be selected using the "+ and -" keys, subsequently press the

"OK" key to accept the channel.

7 ) Highlight C using the "

8 ) A Direct Set using the "+ and -" keys can be entered, subsequently press the "OK" key to

accept the Direct Set value.

and

" arrows highlight A and press the "OK" key. A Direct Set using the "+

and

" keys and press the "OK" key to set the Analog In channel.

and

" keys and press the "OK" key to set the constant value.

Function Blocks 6

PneuAlpha2 Series Controller

and

6 - 30

" keys. The
