- Page 1 Doc.no.AS*-OMG0107-B PRODUCT NAME Speed Controller with One-touch Fitting /Elbow Type/Universal Type MODEL / Series / Product Number ＡＳ*２*１Ｆ ＡＳ*３*１Ｆ...
- Page 2 Contents 1.Saftey Instructions 2～3 2.Specific Product Precautions 4～7 3.Applications 4.Specifications 5.Malfunctions and Countermeasures 6.Construction 9～12 - 1 -...
-
Page 3: Safety Instructions
Speed Controller with One-touch Fitting /Elbow Type/Universal Type Safety Instructions These safety instructions are intended to prevent hazardous situations and/or equipment damage. These instructions indicate the level of potential hazard with the labels of “Caution,” “Warning” or “Danger.” They are all important notes for safety and must be followed in addition to International Standards (ISO/IEC) , and other safety regulations. -
Page 4: Limited Warranty And Disclaimer/Compliance Requirements
Speed Controller with One-touch Fitting /Elbow Type/Universal Type Safety Instructions Caution We develop, design, and manufacture our products to be used for automatic control equipment, and provide them for peaceful use in manufacturing industries. Use in non-manufacturing industries is not covered. Products we manufacture and sell cannot be used for the purpose of transactions or certification specified in the Measurement Act. - Page 5 2. Ensure sufficient space for maintenance activities. 2．Specific Product Precautions When installing the products, allow access for maintenance. Design / Selection 3. Tighten threads with the proper tightening warning torque. When installing the products, follow the listed 1. Confirm the specifications. torque specifications.
-
Page 6: Air Supply
3.It is possible to tighten the lock nut (hexagon) Caution manually. If the nut needs to be fixed more firmly, retighten it with a tool. When using a 1. The tightening torque for various pipe tool, the nut needs to be tightened to the fittings are shown in the table below. -
Page 7: Operating Environment
Maintenance 3. Drain flushing If condensation in the drain bowl is not emptied warning on a regular basis, the bowl will overflow and allow the condensation to enter the compressed 1. Perform maintenance inspection according air lines. It causes malfunction of pneumatic to the procedures indicated in the operation equipment. - Page 8 Recommended Piping Conditions (4) Pull the tubing back gently to make sure it has a positive seal. Insufficient installation may cause 1. When connecting piping air to leak or the tube to release. to the one-touch fitting, 2) Removing of tubing use pipe length with (1) Push flange evenly and push the release button sufficient margin, in...
-
Page 9: Specifications
3．Application This equipment is for a use to control the speed of the actuator. 4．Specifications A I R WORKING FLUID Note 1) １．５ ＭＰａ Proof pressure Max. operating pressure １ ＭＰａ Note 2) Min. operating pressure ０．１ ＭＰａ Ambient and fluid temperature -５... - Page 10 6．Construction Elbow Type <Meter-out Type> < Meter-out Type > AS12＊1F-M3-02 AS12＊1F-M5-02 M3 Type M5 Type U10/32 Type AS22＊1F-01 AS22＊1F-02 AS32＊1F-03 AS42＊1F-04 - 9 -...
-
Page 11: Parts List
AS32＊1F-02 Parts List Description Material Notes Body A ① Note 1) Handle ② PBT Note 2) Body B Electroless nickel plated ③ Brass Needle Brass Electroless nickel plated ④ Needle guide Brass Electroless nickel plated ⑤ Note 3) Seat ring Brass ⑥... - Page 12 Universal Type <Meter-out Type> < Meter-out Type > M3 Type M5 Type U10/32 Type AS23＊1F-01 AS23＊1F-02 AS33＊1F-03 AS43＊1F-04 - 11 -...
- Page 13 AS33＊1F-02 Parts List Description Material Notes Body A ① Elbow body ② Note 1) Handle ③ PBT Note 2) Body B Electroless nickel plated ④ Brass Brass Needle Electroless nickel plated ⑤ Brass Needle guide Electroless nickel plated ⑥ Brass Seat ring ⑦...
- Page 14 Revision history B: Delete SMC address. ”Safety Instruction” changed. Tel: + 81 3 5207 8249 Fax: +81 3 5298 5362 https://www.smcworld.com Note: Specifications are subject to change without prior notice and any obligation on the part of the manufacturer. © SMC Corporation All Rights Reserved - 13 -...
