Chapter 9 - Specifications - HME NEXEO Instruction Manual

Chapter 9 - Specifications

BS7000 Base Station
Dimensions 7.62" H x 12.579" W x 3.669" D (193.55 x 319.51 x 93.19 mm)
Weight 3.5 lb (1.59 kg)
Power Supply Input Voltage: 100 - 240 VAC nominal
Output Voltage: 48 VDC
Current: 1.88 A
LAN Gbit Ethernet
Front Panel LCD type: 800x480 TFT w/ capacitive touch
Rear Panel RJ45 (x5), USB types A & C, PCBA mounted power supply & component headers
Temperature Operating Temperature range: 0°C (+32°F) to +50°C (+122°F).
Compliance See NEXEO | HDX - Regulatory, Compliance, and Safety Guide online
HS7000 All-In-One (AIO) Headset
Dimensions 5.2" H x 5.2" W x 2.1" D (132.1 x 132.1 x 53.3 mm) with boom excluded
9.2" H x 5.2" W x 2.1" D (234.4 x 132.1 x 53.3 mm) with boom extended down
Weight 3.67 oz (104.04 g) with battery included
Power Supply Voltage: 3.7 VDC, powered from a rechargeable Lithium-ion battery
Frequency Range Audio: 100 Hz to 7.4 kHz
Wireless Main Radio: 5.180 GHz – 5.8525 GHz
Secondary Radio: 2.402 GHz - 2.480 GHz
Power, Watts Nominal Power with listening only: 0.314 W
Maximum Power with dedicated mode: 0.407 W
Keypad type Touch Sense
Temperature Operating Temperature range: 0°C (32°F) to +50°C (+122°F)
Storage Temperature range:
Compliance See NEXEO | HDX - Regulatory, Compliance, and Safety Guide online
AC70 Smart Battery Charger
Dimensions 5.09" L x 3.64" W x 1.84" H (129.2 x 92.4 x 46.7 mm)
Weight 5.97 oz (169.19 g)
Power Supply Input Voltage: 100 - 240 VAC nominal
Output Voltage: 5 V; 4 A
MTBF (min.): 300,000 hours demonstrated, Charge Output: ~ 3 W per port
LAN Wireless PAN, 2.4 GHz Wireless Technology
Front Panel Four charging ports for BAT70. LED type: 4 x RGB, for port/battery charging status
Side Panel Four storage ports for BAT70 (Storage ports do not charge)
Temperature Operating Temperature range: 0°C (32°F) to +40°C (+104°F)
Storage: -40°C (-40°F) to +80°C (+176°F) Humidity: 0 - 95%, non-condensing
Compliance See NEXEO | HDX - Regulatory, Compliance, and Safety Guide online
© 2024 HM Electronics, Inc. All rights reserved.
Power: 90 W
-10°C (14°F) to +80°C (+176°F)
9
53
