HME Communicator COM6000 Instructions

Registration instructions
Hide thumbs
1
2
3
4

Advertisement

Table of Contents

These instructions include registration of the COM6000 with both the Wireless IQ™ and ionIQ™ systems.
Prior to operation of the drive-thru audio system, each Communicator must be registered for use with a
specific base station. The base station will then recognize all registered Communicators when their
power is on, differentiating between them and interfering transmissions from other electronic equipment
operating on similar frequencies.
•
A maximum of 15 Communicators can be registered.
•
If a new Communicator is received, or one is returned from repair, it must be registered.
•
When a Communicator is replaced, the old one remains in memory.
•
If the maximum number of 15 Communicators (in memory) is exceeded, some or all current
registrations may need to be cleared before registering others.
•
Communicators must be within 6 feet (1.83 meters) of the base station while being registered.
•
All Communicators to be registered must be powered off and the base station powered on. Other
Communicators can be either on or off.
Wireless IQ
If your base station looks like this
go to page 2
for registration instructions
HM ELECTRONICS, INC.

REGISTRATION INSTRUCTIONS

™
base station
Figure 1. Wireless IQ
Channel "B"
button
Channel "A2"
button
Figure 2. Registration controls on Communicator
14110 Stowe Drive, Poway, CA 92064 USA
COMMUNICATOR
ionIQ
™
If your base station looks like this
go to page 3
for registration instructions
™
and ionIQ
™
base stations
Channel "A1"
button
Power
button
•
Phone: 1-800-848-4468 Fax: (858) 552-0172
COM6000
base station
HME# 400G547
Rev C
®
2/8/10

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Communicator COM6000 and is the answer not in the manual?

Questions and answers

Related Manuals for HME Communicator COM6000

Summary of Contents for HME Communicator COM6000

  • Page 1 Channel “A1” Channel “B” button button Channel “A2” button Power button Figure 2. Registration controls on Communicator HM ELECTRONICS, INC. • 14110 Stowe Drive, Poway, CA 92064 USA Phone: 1-800-848-4468 Fax: (858) 552-0172 HME# 400G547 Rev C 2/8/10...
  • Page 2 ⎯ When the Status light returns to the condition previously noted, press the START REGISTRATION button and repeat the registration procedure. ⎯ If registration fails again, contact HME Technical Support or your local HME representative. See page 1. • When all required Communicators have been registered, close the base station cabinet and reconnect the remote antenna cable to the connector shown in Figure 3.
  • Page 3 ® ™ For ion IQ Audio Systems, register each COMMUNICATOR as follows: • On the ion IQ base station STATUS display, press the Menu button. • On the MAIN MENU display, press the Register button. • The REGISTRATION display indicates the number of headsets already registered and how many more can be registered.
  • Page 4 The European Union (EU) WEEE Directive (2002/96/EC) places an obligation on producers (manufacturers, distributors and/or retailers) to take-back electronic products at the end of their useful life. The WEEE Directive covers most HME products being sold into the EU as of August 13, 2005. Manufacturers, distributors and retailers are obliged to finance the costs of recovery from municipal collection points, reuse, and recycling of specified percentages per the WEEE requirements.
