Introduction

Connect Tech's SMARC/SL Carrier is a super small SMARC Carrier Board ideal for your low power application.
The SMARC/SL Carrier has the ability to use both +3.3V and +1.8V SMARC Modules, a single Mini-
PCIe/mSATA with External SATA switching, Gigabit Ethernet, HDMI Video, and MIPI CSI Camera interface.
The SMARC/SL Carrier supports an extended temperature range of -40
footprint; ideal for mobile or stationary applications.

Product Features and Specifications

Feature
SMARC Compatibility
PCB Size / Overall Size
Display
Ethernet
USB
SATA
Audio
Serial
Mini-PCIe/mSATA
Storage
Camera
Power Operation
Power Requirements
Operating Temperature
Accessories
Warranty and Support

Part Numbers

Feature
SRG001
SRG002
Document: CTIM-00439
Revision: 0.00
ES France - Mobilité & Systèmes Embarqués
127 rue de Buzenval BP 26 - 92380 Garches
SMARC Hardware Specification V1.0 and V1.1
100 x 57.5mm (3.937" x 2.263")
3D STEP Model: download here
1x HDMI
1x Gigabit Ethernet (10/100/1000)
2x USB 2.0
1x External SATA Link (Switchable with Mini-PCIe/mSATA)
HD Audio: 1x Input, 1x Output
1x RS-232
1x Full Sized Mini-PCIe/mSATA (SATA Link Switchable with External
SATA)
1x MicroSD Card Slot
1x MIPI 2-Lane Serial Camera Interface (CSI0 or CSI1)
SMARC V1.0 +VDD_IO Control Circuitry on Board
+VDD_IO Operation at +3.3V and +1.8V Levels
(SMARC V1.1 Ties +VDD_IO to +1.8V)
+6V to +36V DC Input
o o
-40 C to +85 C
Cable Kit
2 Year Warranty and Free Support
SMARC/SL Carrier Board with MIPI CSI-0 Camera Interface
SMARC/SL Carrier Board with MIPI CSI-1 Camera Interface
