Connector Summary

Designator Connector
U10 SMARC
P1 HD Audio
P2 HDMI
P3 Gigabit Ethernet
P4 microSD
P5 External SATA
P7 Mini-PCIe/mSATA
P8 Input Power
P9 Serial
P10 SMARC System
P11 Camera
P12 USB 2.0 Ports 0-1
Jumper Summary & Locations
Designator Function
J1A Reset
J1B Ext SATA/mSATA
Selection
DIP Switch Summary & Locations
Designator Function
S1A BOOT_SEL0#
S1B BOOT_SEL1#
S1C BOOT_SEL2#
S1D Client USB VBUS
Detection
S1E Client USB OTG ID
S1F Client USB Power
Document: CTIM-00439
Revision: 0.00
ES France - Mobilité & Systèmes Embarqués
127 rue de Buzenval BP 26 - 92380 Garches
Description
SMARC MXM 3.0 Module Connector
HD Audio: 1x Input, 1x Output FCI MiniTek Connector
HDMI Display FCI MiniTek Connector
Gigabit Ethernet (10/100/1000) FCI MiniTek Connector
microSD Card Slot
External SATA Molex Connector
Mini-PCIe/mSATA Full Sized Card Slot
Input Power Phoenix Contact Terminal Connector
RS-232 FCI MiniTek Connector
SMARC System Port FCI MiniTek Connector
MIPI 2-Lane Serial Camera Interface Hirose Connector
USB 2.0 Links 0 and 1 FCI MiniTek Connector
Description
Jumper to hard reset the entire Carrier
Jumper to select between External SATA with Mini-PCIe or
mSATA
Description
Input straps determining the SMARC Modules boot device
Input straps determining the SMARC Modules boot device
Input straps determining the SMARC Modules boot device
USB host power detection
USB OTG ID input
USB Client Power control to disable +5V at output
