INTRODUCTION

Connect Tech's SMARC 2.0 carrier is an extremely small SMARC carrier board ideal for low power IoT
applications as users can take advantage of the integrated on-board wireless capabilities found on the
SMARC 2.0 modules. The carrier has USB 3.0, USB 2.0, 2x MIPI CSI-2 camera interfaces, HDMI outputs,
microSD, and expansion via two mini PCIe Full size slots.
Connect Tech's SMARC 2.0 carrier board supports the latest generation Apollo Lake x86 low-powered
processors and exposes next-generation interconnect (USB 3.0, DDI, MIPI-CSI-2).
SMARC 2.0 supports an extended temperature range of -40°C to +85°C and offers a very small footprint;
ideal for mobile or stationary applications.

Product Features and Specifications

Compatibility
Network
Display
USB
Storage
UART Type
I2C
GPIO
Video Input
Expansion
LEDs
Input Power
Dimensions
Operating Temperature

Part Numbers / Ordering Information

SRG004
Document: CTIM-00154
Revision: 0.04
Specifications
All SMARC 2.0 Compliant Modules
2x RJ45 GbE
2x HDMI
2x USB 2.0 (exposed), 2x USB 2.0 (Mini-PCIe), 2x USB 3.0
1x mSATA, 1x microSD
1x RS-232
1x 3.3V I2C port
8 bits of 3.3V I/O
1x MIPI CSI-2 (x2 lane), 1x MIPI CSI-2 (x4 lane)
2x Mini PCIe Full Sized slots (1 slot mSATA capable)
PWR, RESET LEDs
+5V DC Input only (± 5%)
105.8mm x 82.4mm (4.165" x 3.244")
-40°C to +85°C (-40°F to +185°F)
Part Number
SMARC 2.0 Carrier
