Hdmi Connector; 10/100/1000 Ethernet (Gbe) - Connect Tech SMARC/SL User Manual

HDMI Connector

Function HDMI Connector
Location P2
Type FCI MiniTek Double Row 10 x 2
98414-G06-20LF
P/N
Mating 10073599-020LF
Cable CBG145
Pinout Pin Description
1 TMDS2+
3 TMDS2-
5
7 TMDS1+
9 TMDS1-
11
13 TMDS0+
15 TMDS0-
17
19

10/100/1000 Ethernet (GBE)

Function Gigabit Ethernet Connector
Location P3
Type FCI MiniTek Double Row 5 x 2
98414-G06-10LF
P/N
Mating 10073599-010LF
Cable CBG117
Pinout
Pin Description
1
3
5 SHELL
7
9
