INTRODUCTION

Connect Tech's Lepton brings a deployable NVIDIA® Jetson Orin™ NX to the market. The Lepton's design
includes a Locking Power Input (+9 to +36V), Dual Gigabit Ethernet, HDMI video, 4 x USB 3.0 Type A, 4 x
FPD-Link III Cameras, USB Type-C (w/ OTG functionality), M.2 (B-Key 3042, M-Key 2280, and E-Key 2230
functionality; bottom access panel), 40 Pin Locking GPIO connector, 6-Pin Locking Isolated Full-Duplex
CAN, RTC battery, 2FF (mini) SIM card slot, and a dual purpose Reset/Force Recovery pushbutton with
Power LED.
Lepton is compatible with NVIDIA® Jetson Orin™ NX and Orin™ Nano modules. Some I/O performance
will change across modules.

Product Feature and Specifications (Carrier Only)

Feature
Module Compatibility
Mechanical Dimensions
USB
GMSL Cameras
Display
Networking
Storage
Wireless Expansion
Misc. I/O
CAN
Document: CTIM-00107
Revision: 0.00
ES France - Mobilité & Systèmes Embarqués
127 rue de Buzenval BP 26 - 92380 Garches
Not compatible with NVIDA® Jetson Xavier™ NX or Xavier™ Nano.
NVIDIA® Jetson Orin™ NX
NVIDIA® Jetson Orin™ Nano
104mm x 110mm x 34mm
4x USB 3.0 (Connector: USB Type-A)
1x USB 3.1 OTG (Type-C)
1x USB 3.0 + 2.0 Port to M.2 B-Key
1x USB 2.0 to M.2 E-Key
4x FPD-Link III Camera Inputs (Connector: Quad Micro COAX)
Deserializers Embedded On Carrier Board
1x HDMI 2.0 Type-A
2x 10/100/1000BASE-T Uplink (1 Port From PCIe PHY Controller)
1x NVMe (M.2 2280 M-KEY)
1x WiFi Module (M.2 2230 E-KEY)
1x LTE Module (M.2 3042 B-KEY) w/ 2FF SIM Card Connector
1x SPI
2x Isolated Camera Trigger Input
2x UART (1x Console, 1x 3.3V)
1x RS-485
2x I2C
2x PWM OUT
4x GPIO (2x IN, 2x OUT)
2x 5V
2x 3.3V
9x GND
1x Isolated CAN FD (1Mbps max)
